Embedded fanless computers may be small, but they pack a big punch. Small barebone systems offers an alternative computer to the traditional desktop or rackmount.  Offering a variety of expansion configurations while still preforming at full capacity on a i-series processor and only a fraction of the size.

These two systems the E213 and E230 provide you with the latest in computing technology . An affordable system without sacrificing custom ability and performance.

F213

Fanless F213 embedded computer system with 4 I/O

Fanless F213 embedded computer system with 2 I/O

The E213 offers an affordable fanless system jam-packed with a 2nd Gen Core i7, i5, i3 or Celeron processor; a maximum of 8 GB RAM;  and a 250 GB HHD with an optional CFast card.  As well as offering four different options for a expansion configuration.

F230

Fanless F230 embedded computer system with 4 I/O

The E230 is one of the best fanless barebone systems on the market today.  Providing an Fanless F230 embedded computer system with 2 I/Ooptional second SATA HHD, rugged operation temperature up to -10°C~50°C and multiple expansion configuration for your customization.


Model:
8 Isolated DI/DO (4-IN / 4-OUT)
No
Yes
Processor:
2nd Gen Core i7, i5, i3, Celeron
4th Gen Core i7, i5, i3, Celeron
Memory:
2 GB DDR3 (8 GB max)
2 GB DDR3 (16 GB max)
Hard Drive:
250GB
250GB
Expansion Option 1:
1x PCIex1 and 1x PCIex4
1x PCIex1 and 1x PCIex4
Expansion Option 2:
1x PCI and 1x PCIex4
1x PCI and 1x PCIex4
Expansion Option 3:
4x PCI
4x PCI
Expansion Option 4:
2x PCI and 1x PCIex1 and 1x PCIex16
2x PCI and 1x PCIex1 and 1x PCIex16
CFast:
16 – 64 GB Optional
16 – 64 GB Optional
Ethernet:
2x 10/100/1000 Mbps
2x 10/100/1000 Mbps
COM:
4x COM: 3x RS-232; 1x RS-232/422/485
4x COM: 4x RS-232/422/485
USB:
6x USB 2.0
 2x USB 3.0; 4x USB 2.0
Operating System:
Windows 7 Professional
Windows 7 Professional
Fanless Cooling System:
Yes
Yes
Starting Price:
$1,405.00
 $1,405.00
Not finding your ideal expansion layout?
Contact us directly for a custom solution tailored to your exact needs!
